ENVIROFLEX™ INSTALLATION GUIDE

HOW TO INSTALL MASS LOADED VINYL

Plan the job, cut the material, support its weight, keep seams tight, and integrate MLV into the finished wall, ceiling, floor, pipe, or vehicle assembly.
CUT Utility knife
SEAL Treat seams carefully
SUPPORT Plan for material weight
SHOP MLV CALCULATE YOUR PROJECT

BEFORE YOU START

Tools & Materials

Sharp Utility Knife

Use a fresh blade for cleaner cuts

Straight Edge

Guide long, controlled cuts

Fasteners & Washers

Choose support appropriate to the assembly

Seam Treatment

Seal or tape joints as required

Project Guidance

Confirm the method before cutting or fastening

INSTALL BY APPLICATION

Choose Your MLV Installation Type

The core principles are similar—measure, cut, support the material, treat seams, and integrate it into the assembly—but the fastening and finishing approach changes by application.

WALLS

MLV Wall Installation

MLV is typically installed as a continuous barrier within the wall assembly. Plan the layout so sheets are fully supported and seams can be treated before the finish layer is installed.

1

Measure the wall and plan sheet orientation

2

Cut MLV to fit around openings and penetrations

3

Lift and support the material before fastening

4

Fasten securely into framing or an appropriate substrate

5

Butt or overlap seams as required by the assembly

6

Seal seams and penetrations before installing the finish layer

Important: MLV is heavy. Use adequate support and fastening, especially with large sheets or overhead work.

CEILINGS

MLV Ceiling Installation

Ceiling installation requires extra attention to material weight and temporary support. Work in manageable sections and make sure fastening is appropriate for the framing and finished assembly.

1

Measure the ceiling and divide the layout into manageable sections

2

Pre-cut sheets before lifting them overhead

3

Use temporary support or an additional installer

4

Fasten into structural framing at appropriate intervals

5

Treat seams and penetrations continuously

6

Install the finished ceiling layer according to the assembly design

Do not rely on finish material alone to support the full weight of MLV.

FLOORS

MLV Floor Installation

For floors, MLV is commonly used as a continuous mass layer within a floor/ceiling assembly. The finished build-up must remain flat, supported, and compatible with the flooring system above it.

1

Clean and prepare the substrate

2

Dry-fit and cut MLV to the room dimensions

3

Lay material flat without unnecessary folds or buckling

4

Fit pieces tightly and treat seams

5

Trim cleanly around penetrations and perimeter conditions

6

Install the next layer of the floor assembly as specified

MLV is a sound barrier, not a replacement for impact-isolation underlayment when footfall or structure-borne impact noise is the primary concern.

PIPES & DUCTS

MLV Pipe & Duct Installation

For pipes and ducts, MLV is used as part of a flexible wrap or lagging system. The barrier should remain as continuous as practical while allowing safe access to service points and required clearances.

1

Measure the circumference and length to determine cut size

2

Pre-cut manageable pieces of MLV

3

Wrap the barrier around the pipe or duct

4

Secure the wrap without tearing the material

5

Overlap or tightly join adjacent pieces

6

Seal seams and gaps where appropriate for the system

Maintain all manufacturer-required clearances around heat sources, equipment, access panels, and service components.

VEHICLES

MLV Vehicle Installation

In vehicles, MLV can be cut to fit floor pans, wheel wells, doors, partitions, and other areas where added mass can help reduce transmitted road, drivetrain, and exterior noise.

1

Remove trim or flooring needed to access the installation area

2

Clean the substrate and make a paper/template layout when useful

3

Cut MLV to fit around contours, seats, hardware, and access points

4

Dry-fit each piece before final placement

5

Secure the material so it cannot shift or interfere with controls

6

Reinstall trim and verify access to fasteners, drains, wiring, and service points

Do not obstruct airbags, seat mounts, pedals, wiring service points, drains, ventilation, or other safety-critical vehicle components.

WALL INSTALLATION

Wall Installation — Step by Step

Install MLV as a continuous barrier layer with tight seams and adequate support, then complete the wall assembly using the planned finish layers.

Difficulty DIY Friendly
Tools Basic
Cutting Utility Knife
Support Guides Available
1
Step 1

Measure and plan the layout

Measure the wall area, locate penetrations and obstacles, and plan sheet orientation so seams are minimized.

Pro tip Leave enough material for accurate trimming around edges and openings.
2
Step 2

Cut MLV to fit

Place the material on a safe cutting surface and use a sharp utility knife with a straight edge for controlled cuts.

Pro tip Change blades when cutting becomes difficult or ragged.
3
Step 3

Lift, support, and fasten

Position the MLV and secure it with the fastening method appropriate to the wall assembly. Keep the barrier flat and supported.

Pro tip Large pieces are easier and safer with a second person.
4
Step 4

Treat seams and complete the wall

Keep adjoining edges tight, seal or tape seams as required, address penetrations, and install the planned finish layer.

Pro tip Small gaps can become sound paths, so inspect the entire barrier before closing the wall.
SR — Process Steps
VEHICLE APPLICATIONS

Installing MLV in a Vehicle

Use MLV on floors, doors, wheel wells, and interior panels where added mass can help reduce road, drivetrain, and panel noise. Maintain access to drains, fasteners, wiring, service points, and safety equipment.

Process step image
Step 1

Plan the Coverage

Remove trim as needed and identify the floor, door, wheel-well, or panel areas that can accept added barrier mass.

Keep service access in mind
✓
Step 2

Make a Template

Measure carefully or use a paper/cardboard template before cutting MLV around curves, hardware, wiring, and mounting points.

Template complex shapes first
✓
Step 3

Cut and Fit

Trim the MLV with a utility knife, test-fit each piece, and avoid interfering with moving components or drainage paths.

Dry-fit before final placement
✓
Step 4

Secure and Reassemble

Use the planned attachment method, treat seams where appropriate, and reinstall trim or flooring without pinching wiring or controls.

Inspect before closing panels
PIPE & DUCT APPLICATIONS

Pipe Lagging Installation

Use MLV as part of a layered wrap around noisy pipes or ducts, maintaining continuous coverage and carefully treating seams, supports, valves, and penetrations.

1
Step 1

Measure the circumference and length

Measure each pipe or duct section and account for overlaps, fittings, supports, and changes in direction.

Pro tip Plan access around valves and service points.
2
Step 2

Cut manageable wrap sections

Cut MLV into pieces that can be wrapped safely and continuously around the target section.

Pro tip Smaller sections can be easier around elbows and fittings.
3
Step 3

Wrap and support the barrier

Position MLV as part of the planned lagging system and secure it without creating unnecessary gaps or compressing other required layers.

Pro tip Use a support method appropriate to the system.
4
Step 4

Close seams and inspect

Seal or tape seams as required, check around penetrations and supports, and confirm service access remains available.

Pro tip Continuous coverage is the goal.

SOUNDPROOFING RESOURCES

Plan the Rest of the Project

Use these related tools to confirm the material, quantity, and performance context before installation.

GUIDE Resource title Short description of this resource. Learn more GUIDE Resource title Short description of this resource. Learn more GUIDE Resource title Short description of this resource. Learn more FOUNDATION What Is Mass Loaded Vinyl? Review what MLV does and how it is used within different assemblies. Learn about MLV QUANTITY Soundproofing Calculator Estimate surface area, waste allowance, and the roll quantities required. Open calculator PERFORMANCE STC Ratings Explained Understand how material and assembly performance ratings should be interpreted. Understand STC
INSTALLATION FAQ

MLV Installation Questions

General installation guidance for planning, cutting, supporting, seaming, and finishing Mass Loaded Vinyl.

Need Help?

Need help before you cut?

Send us the application and dimensions if you need help choosing an MLV weight, roll size, or material quantity.

Contact us
Common Questions
What tools do I need to cut MLV?

A tape measure, marker, straight edge, and sharp utility knife cover most field cutting. Use a safe cutting surface and replace dull blades.

How should MLV seams be handled?

Keep seams tight and continuous, then use the seam treatment appropriate to the assembly. Avoid leaving open gaps that create direct sound paths.

Can I install MLV by myself?

Small pieces may be manageable alone, but larger rolls and overhead work can be heavy and awkward. Plan adequate support and use additional help where needed.

Where should MLV sit in the finished assembly?

The exact layer position depends on the wall, floor, ceiling, pipe, or vehicle design. Treat MLV as one component of the complete system rather than a standalone finish material.
